TP-Link TL SX3008F JetStream 8 Port 10GE SFP+ L2+ Managed Switch
TP-Link TL SX3008F JetStream 8 Port 10GE SFP+ L2+ Managed Switch - Image 2
TP-Link TL SX3008F JetStream 8 Port 10GE SFP+ L2+ Managed Switch - Image 3

TP-Link TL SX3008F JetStream 8 Port 10GE SFP+ L2+ Managed Switch

$429.00

1 in stock

SKU: TL-SX3008F Category: Brand:

Description

TL-SX3008F

JetStream 8-Port 10GE SFP+ L2+ Managed Switch

  • 10G Lightning-Fast Connections:?8? 10 Gbps?SFP+ Ports enable high-bandwidth connectivity and non-blocking 160 Gbps switching capacity.
  • Integrated into Omada SDN: Zero-Touch Provisioning (ZTP)*, Centralized Cloud Management, and Intelligent Monitoring.
  • Centralized Management: Easy and convenient management with cloud access and Omada app.
  • Static Routing: Route internal traffic for the efficient use of network resources.
  • Robust Security Strategies: Keep your data safe with systems including IP-MAC-Port Binding, ACL, Port Security, DoS Defend, Storm control, DHCP Snooping, 802.1X, and Radius Authentication.
  • Voice and Video Application Optimization: L2/L3/L4 QoS and?IGMP snooping.
  • Standalone Management: Web, CLI (Console Port, Telnet, SSH), SNMP, RMON, and Dual Image bring powerful management capabilities
HARDWARE FEATURES
Interface ? 8? 10GE SFP+ Slots
? 1? RJ45 Console Port
? 1? Micro-USB Console Port
Fan Quantity Fanless
Power Supply 100-240 V AC~50/60 Hz
Dimensions ( W x D x H ) 17.3 ? 7.1 ? 1.7 in (440 ? 180 ? 44 mm)
Mounting Rack Mountable
Max Power Consumption 15.46 W (220 V / 50 Hz)
Max Heat Dissipation 52.75 BTU/hr (220 V / 50 Hz)
PERFORMANCE
Switching Capacity 160 Gbps
Packet Forwarding Rate 119.04 Mpps
MAC Address Table 32 K
Packet Buffer Memory 16 Mbit
Jumbo Frame 9 KB
SOFTWARE FEATURES
Quality of Service ? 8 priority queues
? 802.1p CoS/DSCP priority
? Queue scheduling
– SP (Strict Priority)
– WRR (Weighted Round Robin)
– SP+WRR
? Bandwidth Control
– Port/Flow based Rating Limiting
? Smoother Performance
? Action for Flows
– Mirror (to supported interface)
– Redirect (to supported interface)
– Rate Limit
– QoS Remark
L3 Features ? 16 IPv4/IPv6 Interfaces
? Static Routing
– 48 static routes
? Static ARP
– 128 Static Entries
? Proxy ARP
? Gratuitous ARP
? DHCP Server
? DHCP Relay
– DHCP Interface Relay
– DHCP VLAN Relay
? DHCP L2 Relay
L2 and L2+ Features ? Link Aggregation
– static link aggregation
– 802.3ad LACP
– Up to 8 aggregation groups, containing 8 ports per group
? Spanning Tree Protocol
– 802.1d STP
– 802.1w RSTP
– 802.1s MSTP
– STP Security: TC Protect, BPDU Filter, Root Protect
? Loopback Detection
– Port based
– VLAN based
? Flow Control
– 802.3x Flow Control
– HOL Blocking Prevention
? Mirroring
– Port Mirroring
– CPU Mirroring
– One-to-One
– Many-to-One
– Tx/Rx/Both
L2 Multicast ? IGMP Snooping
– IGMP v1/v2/v3 Snooping
– Fast Leave
– IGMP Snooping Querier
– IGMP Authentication
? IGMP Authentication
? MLD Snooping
– MLD v1/v2 Snooping
– Fast Leave
– MLD Snooping Querier
– Static Group Config
– Limited IP Multicast
? MVR
? Multicast Filtering: 256 profiles and 16 entries per profile
Advanced Features ? Automatic Device Discovery
? Batch Configuration
? Batch Firmware Upgrading
? Intelligent Network Monitoring
? Abnormal Event Warnings
? Unified Configuration
? Reboot Schedule
VLAN ? VLAN Group
– Max 4K VLAN Groups
? 802.1Q Tagged VLAN
? MAC VLAN: 7 Entries
? Protocol VLAN: Protocol Template 16, Protocol VLAN 16
? Private VLAN
? GVRP
? VLAN VPN (QinQ)
– Port-Based QinQ
– Selective QinQ
? Voice VLAN
Access Control List ? Time-based ACL
? MAC ACL
– Source MAC
– Destination MAC
– VLAN ID
– User Priority
– Ether Type
? IP ACL
-Source IP
– Destination IP
– Fragment
– IP Protocol
– TCP Flag
– TCP/UDP Port
– DSCP/IP TOS
– User Priority
? Combined ACL
? Packet Content ACL
? IPv6 ACL
? Policy
– Mirroring
– Redirect
– Rate Limit
– QoS Remark
? ACL apply to Port/VLAN
Security ? IP-MAC-Port Binding
– 512 Entries
– DHCP Snooping
– ARP Inspection
– IPv4 Source Guard: 100 Entries
? IPv6-MAC-Port Binding
– 512 Entries
– DHCPv6 Snooping
– ND Detection
– IPv6 Source Guard: 100 Entries
? DoS Defend
? Static/Dynamic Port Security
– Up to 64 MAC addresses per port
? Broadcast/Multicast/Unicast Storm Control
– kbps/ratio control mode
? 802.1X
– Port base authentication
– Mac base authentication
– VLAN Assignment
– MAB
– Guest VLAN
– Support Radius authentication andaccountability
? AAA (including TACACS+)
? Port Isolation
? Secure web management through HTTPS with SSLv3/TLS 1.2
? Secure Command Line Interface (CLI) management with SSHv1/SSHv2
? IP/Port/MAC based access control
IPv6 ? IPv6 Dual IPv4/IPv6
? Multicast Listener Discovery (MLD) Snooping
? IPv6 ACL
? IPv6 Interface
? Static IPv6 Routing
? IPv6 neighbor discovery (ND)
? Path maximum transmission unit (MTU) discovery
? Internet Control Message Protocol (ICMP) version 6
? TCPv6/UDPv6
? IPv6 applications
– DHCPv6 Client
– Ping6
– Tracert6
– Telnet (v6)
– IPv6 SNMP
– IPv6 SSH
– IPv6 SSL
– Http/Https
– IPv6 TFTP
MIBs ? MIB II (RFC1213)
? Interface MIB (RFC2233)
? Ethernet Interface MIB (RFC1643)
? Bridge MIB (RFC1493)
? P/Q-Bridge MIB (RFC2674)
? RMON MIB (RFC2819)
? RMON2 MIB (RFC2021)
? Radius Accounting Client MIB (RFC2620)
? Radius Authentication Client MIB (RFC2618)
? Remote Ping, Traceroute MIB (RFC2925)
? Support TP-Link private MIB
MANAGEMENT
Omada App Yes. Requiring the use of OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller.
Centralized Management ? Omada Cloud-Based Controller
? Omada Hardware Controller (OC300)
? Omada Hardware Controller (OC200)
? Omada Software Controller
Cloud Access Yes. Requiring the use of OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller.
Zero-Touch Provisioning Yes. Requiring the use of Omada Cloud-Based Controller.
Management Features ? Web-based GUI
? Command Line Interface (CLI) through the console port, telnet
? SNMP v1/v2c/v3
– Trap/Inform
– RMON (1,2,3,9 groups)
? SDM Template
? DHCP/BOOTP Client
? 802.1ab LLDP/LLDP-MED
? DHCP AutoInstall
? Dual Image, Dual Configuration
? CPU Monitoring
? Cable Diagnostics
? EEE
? Password Recovery
? SNTP
? System Log
OTHERS
Certification CE, FCC, RoHS
Package Contents ? TL-SX3008F Switch
? Power Cord
? Quick Installation Guide
? Rackmount Kit
? Rubber Feet
System Requirements Microsoft? Windows? 98SE, NT, 2000, XP, Vista? or Windows 7/8/10/11, MAC? OS, NetWare?, UNIX? or Linux.
Environment ? Operating Temperature: 0?45 ? (32?113 ?);
? Storage Temperature: -40?70 ? (-40?158 ?)
? Operating Humidity: 10?90% RH non-condensing
? Storage Humidity: 5?90% RH non-condensing

Reviews

There are no reviews yet.
