CBL ASY,DB15,M/F,44197,10FT MFR P/NO: MISCDB15M/F-ST-10′ 3R0301693
This product is a standard 10-foot DB15 male-to-female serial extension cable, designed for a variety of legacy and specialized applications. The manufacturer’s part number, MISCDB15M/F-ST-10′, confirms its configuration as a 10-foot male-to-female, straight-through cable for DB15 interfaces. This is not a high-density VGA cable, which has 3 rows of pins, but rather a 2-row DB15 serial cable. These cables are used for extending connections for devices like joysticks, MIDI instruments, and various industrial control systems and legacy networking equipment that use the RS-232 serial protocol. The straight-through wiring (pin 1 to pin 1, 2 to 2, etc.) ensures compatibility with standard serial data applications. The cable’s robust construction, typically featuring molded connectors with thumbscrews, ensures a secure and durable connection. With a length of 10 feet, it provides generous flexibility for arranging devices in a workspace.
System specification
• Cable Type: DB15 Male to DB15 Female Serial Extension Cable
• Length: 10 feet
• Connectors: Male 15-pin (DB15) on one end, Female 15-pin (DB15) on the other
• Pinout: Straight-through wiring (1-to-1)
• Applications: RS-232 serial communication, joysticks, MIDI, and various industrial equipment
• Shielding: Typically shielded to prevent EMI/RFI interference
• Fasteners: Molded connectors with thumbscrews for secure connections
• Manufacturer Part No.: MISCDB15M/F-ST-10′
• Supplier Part No.: 3R0301693
Conclusion
The CBL ASY,DB15,M/F,1-1,10FT is a reliable, high-quality extension cable for extending serial communication over a 10-foot distance. Its robust construction, straight-through wiring, and secure connectors make it a practical solution for professionals working with legacy hardware or specialized industrial devices. The cable’s compliance with standard DB15 serial pinout ensures compatibility and dependable data transfer, offering a valuable and durable component for extending the reach of crucial equipment.
