Description
EAP660 HD
AX3600 Wireless Dual Band Multi-Gigabit Ceiling Mount Access Point
- Ultra-Fast Wi-Fi 6 Speeds:?Simultaneous 1148 Mbps on 2.4 GHz and 2402 Mbps on 5 GHz totals 3550 Mbps Wi-Fi speeds.
- High-Density Connectivity: 4? increased capacity to connect more devices simultaneously.
- Integrated into Omada SDN: Zero-Touch Provisioning (ZTP), Centralized Cloud Management, and Intelligent Monitoring.
- Centralized Management: Cloud access and Omada app for ultra convenience and easy management.
- 2.5G Port:?A 2.5 Gbps Ethernet port boosts?total internet throughput.
- Seamless Roaming: Even video streams and voice calls are unaffected as users move between locations.
- PoE+ Support:?Supports Power over Ethernet (802.3at) for convenient?deployment and installation.
- Secure Guest Network: Along with multiple authentication options (SMS/Facebook Wi-Fi/ Voucher, etc.) and abundant wireless security technologies.
| HARDWARE FEATURES | |
|---|---|
| Interface | 1? 2.5 Gbps Ethernet Port (supports IEEE802.3at PoE) |
| Button | Reset |
| Power Supply | ? 802.3at PoE ? 12 V DC |
| Power Consumption | ? EU: 18.5 W ? US: 21.5 W |
| Dimensions ( W x D x H ) | 9.6 ? 9.6 ? 2.5 in (243 ? 243 ? 64 mm) |
| Antenna Type | Internal Omni ? 2.4 GHz: 4? 4 dBi ? 5 GHz: 4? 5 dBi |
| Mounting | Ceiling /Wall Mounting (Kits included) |
| WIRELESS FEATURES | |
|---|---|
| Wireless Client Capacity | 1,000+*** |
| Wireless Standards | IEEE 802.11ax/ac/n/g/b/a |
| Frequency | 2.4 GHz and 5 GHz |
| Signal Rate | ? 5 GHz: Up to 2402 Mbps ? 2.4 GHz: Up to 1148 Mbps |
| Wireless Functions | ? 1024-QAM ? 4? Longer OFDM Symbol ? OFDMA ? Multiple SSIDs (Up to 16 SSIDs, 8 for each band) ? Enable/Disable Wireless Radio ? Automatic Channel Assignment ? Transmit Power Control (Adjust Transmit Power on dBm) ? QoS(WMM) ? MU-MIMO ? Seamless Roaming? ? Omada Mesh? ? Band Steering ? Load Balance ? Airtime Fairness ? Beamforming ? Rate Limit ? Reboot Schedule ? Wireless Schedule ? Wireless Statistics based on SSID/AP/Client |
| Wireless Security | ? Captive Portal Authentication? ? Access Control ? Wireless Mac Address Filtering ? Wireless Isolation Between Clients ? SSID to VLAN Mapping ? Rogue AP Detection ? 802.1X Support ? WEP, WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise |
| Transmission Power | ? CE: <20 dBm(2.4 GHz, EIRP) <23 dBm(5 GHz, EIRP)? FCC: <26 dBm (2.4 GHz) <26 dBm (5 GHz) |
| MANAGEMENT | |
|---|---|
| Omada App | Yes |
| Centralized Management | ? Omada Cloud-Based Controller ? Omada Hardware Controller (OC300) ? Omada Hardware Controller (OC200) ? Omada Software Controller |
| Cloud Access | Yes (Through OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller) |
| Email Alerts | Yes |
| LED ON/OFF Control | Yes |
| Management MAC Access Control | Yes |
| SNMP | v1, v2c, v3 |
| System Logging Local/Remote Syslog | Local/Remote Syslog |
| SSH | Yes |
| Web-based Management | HTTP/HTTPS |
| L3 Management | Yes |
| Multi-site Management | Yes |
| Management VLAN | Yes |
| Zero-Touch Provisioning | Yes. Requiring the use of Omada Cloud-Based Controller. |
| OTHERS | |
|---|---|
| Certification | CE, FCC, RoHS |
| Package Contents | ? EAP660 HD ? Power Adapter ? Ceiling/Wall Mounting Kits ? Installation Guide |
| System Requirements | Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Windows11, Linux |
| Environment | ? Operating Temperature: 0?40 ? (32?104 ?) ? Storage Temperature: -40?70 ? (-40?158 ?) ? Operating Humidity: 10?90% RH non-condensing ? Storage Humidity: 5?90% RH non-condensing |
