PowerColor RX9060XT 16G-L/OC/WHITE Radeon RX 9060 XT | Hellhound Spectral White 16GB GPU
- RDNA 4 Architecture: AMD’s latest GPU engine with 3rd Gen raytracing and AI acceleration for ultra-responsive gameplay.
- 16GB GDDR6 Memory: Generous high-speed memory for demanding 1440p gaming and next-gen visual workloads.
- PCIe 5.0 x16 Interface: Future-ready bandwidth ensures maximum compatibility and throughput for modern systems.
- Triple-Ring Fan Cooling: Intelligent 9-blade ring fans with dual ball bearings and vertical heatsink design for quiet efficiency.
- Honeywell PTM7950 Thermal Pad: High-performance phase-change material enhances GPU-to-heatsink thermal transfer.
- Dual BIOS Mode: Easily toggle between OC and Silent profiles for personalized performance tuning.
- 10-Layer Premium PCB: Features 2oz copper layers and high-grade polymer capacitors for thermal durability and signal stability.
- Glacier White ARGB Lighting: Subtle white illumination controlled via a physical switch to match minimal or white-themed builds.
SPECIFICATIONS
| Graphics Engine | AMD Radeon™ RX 9070 XT |
| Model Name | RX9070XT 16G-L/OC/WHITE |
| Series | Hellhound |
| Stream Processor | 4096 Units |
| Video Memory | 16GB GDDR6 |
| Memory Speed | 20.0 Gbps |
| Memory Interface | 256-bit |
| Engine Clock (OC) | up to 2460MHz(Game)¹ up to 3010MHz(Boost)² |
| Engine Clock (STD/Silent) | up to 2400MHz(Game)¹ up to 2970MHz(Boost)² |
| Bus Standard | PCIE 5.0 x16 |
| Standard Display Connectors | 1 x HDMI 2.1b，3 x DisplayPort 2.1a (only 2x simultaneous DP2.1 connections can be supported) |
| Feature Support | |
| Direct X Support | 12 |
| Open GL | 4.6 |
| AMD Stream Technology | Support |
| AMD Eyefinity Technology | Support |
| AMD Smart Access Memory | Support |
| Maximum Resolution | |
| DisplayPort | 7680×4320 |
| HDMI | 7680×4320 |
| Power Specs + Board Dimensions | |
| Board Dimension | 327mm*128mm*49mm 340mm*142mm*49mm(with bracket) |
| Slot | 2.5 |
| Minimum System Power requirement (W) | 800W |
| Extension Power Connector | Two 8-pin PCI Express Power connectors |
