Description
ROG Strix GeForce RTX? 4090 OC Edition 24GB GDDR6X
- AI Performance: 1368 AI TOPS
- NVIDIA Ada Lovelace Streaming Multiprocessors:?Up to 2x performance and power efficiency
- 4th Generation Tensor Cores:?Up to 4x performance with DLSS 3 vs. brute-force rendering
- 3rd Generation RT Cores:?Up to 2X ray tracing performance
- OC mode:?Boost clock?2640?MHz (OC mode)/?2610?MHz (Gaming mode)?
- Axial-tech fans?scaled up for 23% more airflow
- New patented vapor chamber?with milled heatspreader for lower GPU temps?
- 3.5-slot design:?massive fin array optimized for airflow from the three Axial-tech fans
- Diecast shroud, frame, and backplate?add rigidity and are vented to further maximize airflow and heat dissipation
- Digital power?control?with high-current power stages and 15K capacitors to fuel maximum performance
- Auto-Extreme?precision automated manufacturing for higher reliability
- GPU Tweak III?software provides intuitive performance tweaking, thermal controls, and system monitoring
SPECIFICATIONS
Graphic Engine
NVIDIA? GeForce RTX? 4090
AI Performance
1368
Bus Standard
PCI Express 4.0
OpenGL
OpenGL?4.6
Video Memory
24GB GDDR6X
Engine Clock
OC mode: 2640 MHz
Default mode: 2610 MHz (Boost Clock)
Default mode: 2610 MHz (Boost Clock)
CUDA Core
16384
Memory Speed
21 Gbps
Memory Interface
384-bit
Resolution
Digital Max Resolution 7680 x 4320
Interface
Yes x 2 (Native HDMI 2.1a)
Yes x 3 (Native DisplayPort 1.4a)
HDCP Support Yes (2.3)
Maximum Display Support
4
NVlink/ Crossfire Support
No
Accessories
1 x Collection Card?
1 x Speedsetup Manual?
1 x Adapter Cable?
1 x ROG Graphics Card Holder
1 x ROG Velcro Hook & Loop
1 x Thank you Card
1 x Speedsetup Manual?
1 x Adapter Cable?
1 x ROG Graphics Card Holder
1 x ROG Velcro Hook & Loop
1 x Thank you Card
Software
ASUS GPU Tweak III & GeForce Game Ready Driver & Studio Driver: please download all software from the support site.
Dimensions
357.6 x 149.3 x 70.1mm
Recommended PSU
1000W
Power Connectors
1 x 16-pin
Slot
3.5 Slot
Reviews
There are no reviews yet.
