Description
ROG-STRIX-750G
- ROG heatsinks cover critical components. Lower temps result in a longer lifespan and reduced noise.
- Axial-tech fan design features a smaller fan hub that facilitates longer blades and a barrier ring that increases downward air pressure.
- Dual ball fan bearings can last up to twice as long as sleeve bearing designs.
- 0dB Technology lets you enjoy light gaming in relative silence.
- An 80 Plus Gold Certification is the result of Japanese capacitors and other premium components.
- Cosmetic customization is enabled by a magnetic logo and stickers that help you reskin the visible side to your liking.
- Fully modular cables keep your rig neat and tidy.
SPECIFICATIONS
Intel Specification
ATX12V
PFC Type
Active PFC
Dimensions
16 x 15 x 8.6 Centimeter
Efficiency
80Plus Gold
MTBF
>120,000 hrs @ 25°C
Protection Features
OPP/OVP/UVP/SCP/OCP/OTP
Hazardous Materials
ROHS
AC Input Range
100-240Vac
RGB Connector
NA
Fan Size
135mm
DC Output Voltage
+3.3V +5V +12V -12V +5Vsb
Maximum Load
20A 20A 62A 0.3A 3A
Total Output
750W
Cable Connectors
MB 24/20-pin x 1
CPU 4+4-pin x 2
PCI-E 6+2-pin x 4
SATA x 8
Peripheral x 3
CPU 4+4-pin x 2
PCI-E 6+2-pin x 4
SATA x 8
Peripheral x 3
Package Contents
Power Cord x 1
Motherboard Power Cable x1 (610mm)
CPU Cable x 2 (1000mm)
PCIE 1-to-2 Cable x2 (675+75mm)
SATA 1-to-4 Cable x1 (410+150+150+150mm)
SATA 1-to-4 Cable x1 (450+120+120+120mm)
Peripheral 1-to-3 Cable x1 (450+120+120mm)
Join the ROG badge x 2
ROG logo magnet x 1
ROG label x 3
Motherboard Power Cable x1 (610mm)
CPU Cable x 2 (1000mm)
PCIE 1-to-2 Cable x2 (675+75mm)
SATA 1-to-4 Cable x1 (410+150+150+150mm)
SATA 1-to-4 Cable x1 (450+120+120+120mm)
Peripheral 1-to-3 Cable x1 (450+120+120mm)
Join the ROG badge x 2
ROG logo magnet x 1
ROG label x 3
