ROG LOKI SFX-L 1000W Platinum
THE QUEITEST SFX-L PSU
Taking after the ROG Thor, the ROG Loki SFX-L Platinum brandishes the same enthusiast-grade components and features, all packed into an SFX-L form factor. Boasting quiet operation and high performance, the Loki is primed to power your next SFF build.
ROG HEATSINKS
ROG heatsinks facilitate lower temperatures, longer component lifespan, and extended 0dB operation.
AXIAL-TECH FAN DESIGN
Axial-tech fan design features a smaller fan hub that facilitates longer blades and a barrier ring that increases downward air pressure. For ROG Loki PSUs, we’ve scaled that design to 120mm so it keeps things cool at low RPMs while producing less noise.
DUAL BALL FAN BEARINGS
The fan impeller spins on a dual ball bearing setup that will last up to twice as long as a sleeve bearing design
SPECIFICATIONS
Intel Form Factor
SFX-L
PFC Type
Active PFC
ATX Standard
ATX 3.0
Dimensions
125 x 125 x 63.5 mm
Efficiency
80Plus Platinum
MTBF
>120,000 hrs @ 25?C
Protection Features
OPP/OVP/UVP/SCP/OCP/OTP
Hazardous Materials
ROHS
AC Input Range
100-240Vac
DC Output Voltage
+3.3V +5V +12V -12V +5Vsb
Maximum Load
20A 20A 83.3A 0.8A 2.5A
Combined Load
110W 110W 1000W 9.6W 12.5W
Total Output
1000W
Cable Connectors
MB 24/20-pin x 1
CPU 4+4-pin x 2
PCI-E 16-pin x 1 (both PSU & component side)
PCI-E 8-pin x 3
SATA x 6
PERIPHERAL x 4
CPU 4+4-pin x 2
PCI-E 16-pin x 1 (both PSU & component side)
PCI-E 8-pin x 3
SATA x 6
PERIPHERAL x 4
Package Contents
Power Cord x 1
Motherboard Power Cable x 1 (450mm)
CPU Cable x 2 (550mm)
PCI-E Gen 5 16-pin Cable x 1 (450mm)
PCI-E (16-pin to 8-pin-8-pin) Cable x 1 (450mm)
PCI-E 1-to-1 Cable x 1 (450mm)
SATA 1-to-3 Cable x 2 (300+200+100mm)
Peripheral 1-to-4 Cable x 1 (300+100+100+100mm)
Addressable RGB Cable x 1 (800mm)
User Manual x 1
ATX to SFX adapter bracket x 1
Motherboard Power Cable x 1 (450mm)
CPU Cable x 2 (550mm)
PCI-E Gen 5 16-pin Cable x 1 (450mm)
PCI-E (16-pin to 8-pin-8-pin) Cable x 1 (450mm)
PCI-E 1-to-1 Cable x 1 (450mm)
SATA 1-to-3 Cable x 2 (300+200+100mm)
Peripheral 1-to-4 Cable x 1 (300+100+100+100mm)
Addressable RGB Cable x 1 (800mm)
User Manual x 1
ATX to SFX adapter bracket x 1
Weight
1.83kg (single PSU)
AURA SYNC
ARGB
