Description
ProArt Display PA32UCR-K
- 32-inch 4K HDR display features mini-LED backlight with 1,000 cd/m2 peak brightness
- Quantum-dot technology provides 99.5% Adobe RGB, 98% DCI-P3 and 100% sRGB color space for exceptional color fidelity
- Support multiple HDR formats (HDR-10, HLG) presents lifelike experience and flexibility
- World-leading delta-E (∆E) <1 color difference value and ASUS ProArt Hardware Calibration technology for color-accuracy optimization, uniformity and color profile write-back
- USB-C supports DisplayPort signal, data transfers and up to 80W Power Delivery to external devices via one cable
- X-rite i1 Display Pro included
SPECIFICATIONS
Model
ProArt Display PA32UCR-K
Display
Panel Size (inch) : 32
Pixels Per Inch (PPI) : 138
Aspect Ratio : 16:9
Display Surface : Non-Glare
Backlight Type : Mini-LED
Panel Type : IPS
Viewing Angle (CR≧10, H/V) : 178°/ 178°
Pixel Pitch : 0.1845mm
Resolution : 3840×2160
Color Space (sRGB) : 100%
Color Space (Adobe RGB) : 99.5%
Color Space (DCI-P3) : 98%
Color Space (Rec.2020) : 87%
Brightness (HDR, Peak) : 1,000 cd/㎡
Brightness (Typ.) : 400cd/㎡
Contrast Ratio (HDR, Max) : 1,000,000:1
Contrast Ratio (Typ.) : 1000:1
Display Colors : 1073.7M (10 bit)
Response Time : 5ms(GTG)
Refresh Rate (Max) : 60Hz
HDR (High Dynamic Range) Support : HDR10
HDR (High Dynamic Range) Support : HLG
Flicker-free : Yes
LCD ZBD Warranty : Yes(3 yr)
Pixels Per Inch (PPI) : 138
Aspect Ratio : 16:9
Display Surface : Non-Glare
Backlight Type : Mini-LED
Panel Type : IPS
Viewing Angle (CR≧10, H/V) : 178°/ 178°
Pixel Pitch : 0.1845mm
Resolution : 3840×2160
Color Space (sRGB) : 100%
Color Space (Adobe RGB) : 99.5%
Color Space (DCI-P3) : 98%
Color Space (Rec.2020) : 87%
Brightness (HDR, Peak) : 1,000 cd/㎡
Brightness (Typ.) : 400cd/㎡
Contrast Ratio (HDR, Max) : 1,000,000:1
Contrast Ratio (Typ.) : 1000:1
Display Colors : 1073.7M (10 bit)
Response Time : 5ms(GTG)
Refresh Rate (Max) : 60Hz
HDR (High Dynamic Range) Support : HDR10
HDR (High Dynamic Range) Support : HLG
Flicker-free : Yes
LCD ZBD Warranty : Yes(3 yr)
Features
Trace Free Technology : Yes
ProArt Preset : Standard
ProArt Preset : sRGB
ProArt Preset : Adobe RGB
ProArt Preset : DCI-P3
ProArt Preset : Rec.2020
ProArt Preset : DICOM
ProArt Preset : Rec.709
ProArt Preset : HDR_PQ DCI
ProArt Preset : HDR_PQ Rec.2020
ProArt Preset : HDR_HLG BT.2100
ProArt Preset : HDR_HLG DCI
ProArt Preset : User mode1
ProArt Preset : User mode2
Color Temp. Selection : Yes(5 modes)
Color Adjustment : 6-axis adjustment(R,G,B,C,M,Y)
Gamma Adjustment : Yes (Support Gamma 1.8/2.0/2.2/2.4/2.6 )
Color Accuracy : △E< 1
ASUS ProArt Hardware Calibration : Yes
ProArt Palette : Yes
QuickFit Plus : Yes
PIP / PBP Technology : Yes
HDCP : Yes, 2.2
Motion Sync : Yes
HDR Preview : Yes
Low Blue Light : Yes
ProArt Preset : Standard
ProArt Preset : sRGB
ProArt Preset : Adobe RGB
ProArt Preset : DCI-P3
ProArt Preset : Rec.2020
ProArt Preset : DICOM
ProArt Preset : Rec.709
ProArt Preset : HDR_PQ DCI
ProArt Preset : HDR_PQ Rec.2020
ProArt Preset : HDR_HLG BT.2100
ProArt Preset : HDR_HLG DCI
ProArt Preset : User mode1
ProArt Preset : User mode2
Color Temp. Selection : Yes(5 modes)
Color Adjustment : 6-axis adjustment(R,G,B,C,M,Y)
Gamma Adjustment : Yes (Support Gamma 1.8/2.0/2.2/2.4/2.6 )
Color Accuracy : △E< 1
ASUS ProArt Hardware Calibration : Yes
ProArt Palette : Yes
QuickFit Plus : Yes
PIP / PBP Technology : Yes
HDCP : Yes, 2.2
Motion Sync : Yes
HDR Preview : Yes
Low Blue Light : Yes
Audio
Speaker : Yes(2Wx2)
I/O Ports
USB-C x 1 (DP Alt Mode)
DisplayPort 1.2 x 1
HDMI(v2.0) x 3
USB Hub : 3x USB 3.2 Gen 1 Type-A
Earphone Jack : Yes
USB-C Power Delivery : 80W
DisplayPort 1.2 x 1
HDMI(v2.0) x 3
USB Hub : 3x USB 3.2 Gen 1 Type-A
Earphone Jack : Yes
USB-C Power Delivery : 80W
Signal Frequency
Digital Signal Frequency : 40~144 KHz (H) / 30~60 Hz (V)
Power Consumption
Power Consumption : 28.92 W
Power Saving Mode : < 0.5 W
Power Off Mode : 0W (hard switch)
Voltage : 100-240V, 50/60Hz
Power Saving Mode : < 0.5 W
Power Off Mode : 0W (hard switch)
Voltage : 100-240V, 50/60Hz
Mechanical Design
Tilt : Yes (+23° ~ -5°)
Swivel : Yes (+30° ~ -30°)
Pivot : Yes (+90° ~ -90°)
Height Adjustment : 0~130mm
VESA Wall Mounting : 100x100mm
Kensington Lock : Yes
Swivel : Yes (+30° ~ -30°)
Pivot : Yes (+90° ~ -90°)
Height Adjustment : 0~130mm
VESA Wall Mounting : 100x100mm
Kensington Lock : Yes
Dimensions (Esti.)
Phys. Dimension (W x H x D) : 72.69 x 60.42 x 47.42 cm (28.62″ x 23.79″ x 18.67″)
Phys. Dimension without Stand (W x H x D) : 72.69 x 42.59 x 6.87 cm (28.62″ x 16.77″ x 2.70″)
Box Dimension (W x H x D) : 91.30 x 36.50 x 52.10 cm (35.94″ x 14.37″ x 20.51″)
Phys. Dimension without Stand (W x H x D) : 72.69 x 42.59 x 6.87 cm (28.62″ x 16.77″ x 2.70″)
Box Dimension (W x H x D) : 91.30 x 36.50 x 52.10 cm (35.94″ x 14.37″ x 20.51″)
Weight (Esti.)
Net Weight : 12.3 kg (27.12 lbs)
Net Weight without Stand : 7.7 kg (16.98 lbs)
Gross Weight : 17.7 kg (39.02 lbs)
Net Weight without Stand : 7.7 kg (16.98 lbs)
Gross Weight : 17.7 kg (39.02 lbs)
