| Network Standard |
IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IPv4, IPv6 |
| Product Segment |
AC1900 ultimate AC performance : 600 1300 Mbps |
| Coverage |
Large homes |
| Data Rate |
802.11n : up to 450 Mbps |
|
802.11n TurboQAM : up to 600 Mbps |
|
802.11ac : up to 1300 Mbps |
| Antenna |
External antenna x 3 |
| Transmit/Receive |
MIMO technology |
|
2.4 GHz 3 x 3 |
|
5 GHz-1 3 x 3 |
| Memory |
128 MB Flash |
|
256 MB RAM |
| Operating Frequency |
2.4 GHz / 5 GHz |
| Encryption |
64-bit WEP, 128-bit WEP, WPA2-PSK, WPA-PSK, WPA-Enterprise , WPA2-Enterprise , WPS support |
| Firewall & Access Control |
Firewall：SPI intrusion detection,DoS protection |
|
Access control：Parental control, Network service filter, URL filter, Port filter |
| Management |
UPnP, IGMP v1/v2/v3, DNS Proxy, DHCP, NTP Client, DDNS, Port Trigger, Universal Repeater, System Event Log |
| WAN Connection Type |
Internet connection type : Automatic IP, Static IP, PPPoE(MPPE supported), PPTP, L2TP |
|
WAN Bridge support |
|
Multicast Proxy support |
|
Multicast Rate Setting support |
| Ports |
RJ45 for 10/100/1000/Gigabits BaseT for LAN x 4, RJ45 for 10/100/1000/Gigabits BaseT for WAN x 1 |
|
USB 2.0 x 1 |
|
USB 3.0 x 1 |
| Button |
WPS Button, Reset Button, Power Button, Wireless on/off Button |
| Features |
Airtime Fairness |
|
Adaptive QoS |
|
AiProtection |
|
Parental Control |
|
Guest Network : 2.4 GHz x 3, 5 GHz x 3 |
|
VPN server : IPSec Pass-Through, PPTP Pass-Through, L2TP Pass-Through, PPTP Server, OpenVPN Server |
|
VPN client : PPTP client, L2TP client, OpenVPN client |
|
Mac OS Backup |
|
Enhanced media server (AiPlayer app compatible) |
|
Image : Jpeg |
|
Audio : mp3, wma, wav, pcm, mp4, lpcm, ogg |
|
Video : asf, avi, divx, mpeg, mpg, ts, vob, wmv, mkv, mov |
|
AiCloud personal cloud service |
|
3G/4G data sharing |
|
Printer Server |
|
Multifunctional printer support (Windows only) |
|
LPR protocol support |
|
Download Master |
|
Support bt, nzb, http, ed2k |
|
Support encryption, DHT, PEX and magnet link |
|
Upload and download bandwidth control |
|
Download scheduling |
|
AiDisk file server |
|
Samba and FTP server with account management |
|
Dual WAN |
|
IPTV support |
|
Roaming Assist |
| LED Indicator |
Power x 1 |
|
Wi-Fi x 2 |
|
LAN x 4 |
|
WAN x 1 |
|
USB x 2 |
| Power Supply |
AC Input : 110V~240V(50~60Hz) |
|
DC Output : 19 V with max. 1.75 A current |
| OS Support |
Windows® 10 |
|
Windows® 8.1 |
|
Windows® 8 |
|
Windows® 7 |
|
Windows® Vista |
|
Windows® 2000 |
|
Windows® ME |
|
Windows® XP |
|
Windows® Server 2003 |
|
Windows® Server 2008 |
|
Mac OS X 10.1 |
|
Mac OS X 10.4 |
|
Mac OS X 10.5 |
|
Mac OS X 10.6 |
|
Mac OS X 10.7 |
|
Mac OS X 10.8 |
|
Mac OS X |
|
Linux Kernel (Support Ubuntu only) |
|
Linux |
| Dimensions |
220 x 83.3 x 160 ~ mm (WxDxH) (Without Bezel) |
| Package Content |
1 x RT-AC68U Wireless-AC1900 Dual Band Gigabit Router |
|
1 x RJ-45 cable |
|
1 x Power adapter |
|
1 x QSG |
|
1 x Support CD(user manual and ultility) |
| Operation mode |
Wireless router mode |
|
Range extender mode |
|
Access point mode |
|
Media bridge mode |
