Ubiquiti LocoM5 UISP airMAX NanoStation M5 loco – 5 GHz Outdoor CPE, 802.11a/n, Integrated Antenna
📦 Product Overview
The Ubiquiti NanoStation LocoM5 is a compact, cost‑effective outdoor CPE designed for 5 GHz point‑to‑point and point‑to‑multipoint wireless links. With integrated airMAX technology, it delivers low‑latency performance, extended range, and easy deployment for WISP networks and outdoor connectivity projects.
🌟 Top Highlights
📡 5 GHz Outdoor CPE – Stable long‑range connectivity
⚡ airMAX TDMA Technology – Improved scalability and reduced latency
📶 Integrated Antenna – Simplified installation with compact design
🔌 Passive PoE Support – Flexible power options
🌐 UISP Compatibility – Remote monitoring and management
📐 Technical Details
| Specification | Details |
|---|---|
| Dimensions | 163 x 31 x 80 mm |
| Weight | 180 g |
| Networking Interface | 1x 10/100 Mbps RJ45 Ethernet port |
| WiFi Standard | 802.11a/n |
| Operating Frequency | 5.1 – 5.8 GHz |
| Max Throughput | 150+ Mbps |
| Antenna Gain | 13 dBi |
| Max TX Power | 23 dBm |
| Power Method | Passive PoE (24V, 0.5A adapter included) |
| Max Power Consumption | 5.5 W |
| LED Indicators | Power, LAN, WLAN, Signal Strength |
| Operating Temperature | -30 to 70 °C |
| Operating Humidity | 5 to 95% noncondensing |
| Certifications | CE, FCC, IC, RoHS, NDAA Compliant |
💡 Why You Should Buy It
✅ Compact and lightweight for easy installation
✅ Reliable 5 GHz connectivity for outdoor links
✅ Integrated antenna reduces deployment complexity
✅ UISP support for centralized management
🎯 Recommended Use Cases
➤ Point-to-point wireless bridging
➤ Point-to-multipoint WISP deployments
➤ Outdoor surveillance backhaul
➤ Extending rural or remote connectivity
🤝 Customer Assurance
🛡️ Warranty / Guarantee: Coverage available through manufacturer support
🔄 Returns Policy: Returns accepted as per standard reseller terms and conditions
🚚 Shipping Info: Delivery handled by reliable logistics partners with tracking support
📞 Customer Support: Assistance available via authorized resellers and support partners
👉 Call to Action
Deploy the NanoStation LocoM5 for cost‑effective, high‑performance outdoor wireless connectivity
