Ubiquiti UniFi UFiber WiFi
The Ubiquiti UFiber UF-WIFI GPON (Gigabit Passive Optical Network) Unit is a robust, high-performance GPON CPE that features a sleek industrial design, an informational LED display with four (4) Ethernet ports, and WiFi. Its compact form factor makes it suitable for wall-mounting, and it is powered by 24V passive PoE, allowing a single cable to carry both power and data. The UFiber network is intelligently managed using the included UNMS
SPECIFICATIONS
| Dimensions | 126.34 x 126.09 x 31.65 mm |
| Weight | 0.19kg |
| Networking Interface | (1)SC/APC, GPON WAN (4)10/100/1000 Mbps Ethernet Ports (1)Wi-Fi, 802.11n |
| Networking Interface Speeds GPON WAN, ITU G.984 GbE LAN Wi-Fi |
2.488 Gbps Downstream, 1.244 Gbps Upstream 10/100/1000 Mbps 300 Mbps |
| Management Interface | In-Band Ethernet/PON |
| Normal Optical Power Range | TX (Class B+): 1.5 to 5dBm, RX:-28 to -8dBM |
| Power Method | DC Jack, 24VDC 24V Passive PoE(Pins 4,5+;7,8- |
| Power Supply | 100-240VAC / 50-60 Hz Universal AC/DC Power Adapter: 24V / 0.5A |
| Max. Power Consumption | 7W |
| Supported Voltage Range | 20 to 28V |
