TL-WA820RE
300Mbps USB Wi-Fi Range Extender
- Superior Extension ? Two external antennas expand your home’s wireless coverage, creating reliable connections and eliminating dead zones
- Compact Design ? Miniature size and USB port design maximize flexible deployment and mobility
- 300Mbps Wi-Fi ? Ideal speeds for video and music streaming
- WPS ? Easily expand wireless coverage at a push of the WPS button
- Intelligent Signal Light ?Helps to determine the best?location for optimal Wi-Fi coverage by indicating the signal strength in the current placement
- TP-Link Tether App ? Easily access and manage your network using any iOS or Android mobile device
- Ultimate Compatibility ? Extend the range of any Wi-Fi router or wireless access point.
| HARDWARE FEATURES | |
|---|---|
| Standards and Protocols | IEEE 802.11n, IEEE 802.11g, IEEE 802.11b |
| Plug Type | USB |
| Interface | None |
| Button | Reset/WPS |
| Input Power | 100-240V~50/60Hz |
| Power Consumption | 2.5W MAX |
| Dimensions ( W x D x H ) | 89.41*36.6*14.3mm |
| Antenna | 2*external |
| WIRELESS FEATURES | |
|---|---|
| Frequency | 2.4GHz |
| Signal Rate | 2.4GHz:Up to 300Mpbs |
| Reception Sensitivity | “2.4GHz 11g 54M: -79dBm@10% PER 11n HT20 mcs7: -77dBm@10% PER 11n HT40 mcs7: -74dBm@10% PER” |
| Transmit Power | <18dBm |
| Wireless Modes | Range Extender |
| Wireless Functions | Power Schedule Access Control LED Control Wi-Fi Coverage” |
| Wireless Security | 64/128-bit WEP WPA-PSK / WPA2-PSK” |
| OTHERS | |
|---|---|
| Certification | CE,RoHS |
| Package Contents | 300Mbps Wi-Fi Range Extender TL-WA820RE Quick Installation Guide” |
| Box Dimensions (W X D X H) | 156.5*101.5*30mm |
| System Requirements | Microsoft? Windows? 98SE, NT, 2000, XP, Vista or Windows 7, 8, 10, Mac? OS, NetWare?, UNIX? or Linux. |
| Environment | Operating Temperature: 0?C~40?C (32?F~104?F) Storage Temperature: -40?C~70?C (-40?F~158?F) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing” |
