🛍️ Product Name
TP-Link SG2005P-PD Omada | 5-Port Gigabit Smart Managed Switch | 1-Port PoE++ Input | 4-Port PoE+ Output | Fanless Metal Housing
📦 Product Overview
The TP-Link SG2005P-PD Omada is a compact smart managed switch designed for small business and edge deployments. Featuring one PoE++ input port and four PoE+ output ports, it simplifies installation by powering itself and connected devices without a separate power supply. With Gigabit connectivity, Omada SDN integration, and a fanless design, it delivers reliable performance in a space-saving form factor.
🌟 Top Highlights
⚡ PoE++ Input – Powers the switch via upstream PoE++
🔌 4 × PoE+ Output Ports – Supplies up to 65W total for IP cameras, APs, or VoIP phones
📡 Gigabit Connectivity – Ensures fast and stable wired networking
🛡️ Omada SDN Integration – Centralized cloud management and monitoring
🌿 Fanless Metal Housing – Silent operation with durable build quality
📐 Technical Details
| Specification | Details |
|---|---|
| Model | SG2005P-PD Omada |
| Ports | 5 × Gigabit RJ45 (1 × PoE++ In, 4 × PoE+ Out) |
| PoE Standards | IEEE 802.3af/at/bt compliant |
| PoE Budget | Up to 65W total output |
| Switching Capacity | 10Gbps |
| Forwarding Rate | 7.44Mpps |
| Management | Web, CLI, SNMP, Omada SDN |
| Features | VLAN, QoS, IGMP Snooping, ACL, Port Mirroring |
| Housing | Fanless metal design |
| Dimensions | Approx. 100 × 100 × 25 mm |
| Weight | Approx. 0.35 kg |
| Operating Temperature | 0°C to 40°C |
| Storage Temperature | -40°C to 70°C |
| Humidity | 10%–90% non-condensing |
💡 Why You Should Buy It
✅ Powers itself via PoE++ without external adapter
✅ Provides PoE+ output for multiple powered devices
✅ Compact, silent, and durable design
✅ Smart management with Omada SDN integration
🎯 Recommended Use Cases
➤ Powering IP cameras in small deployments
➤ Supplying PoE to wireless access points
➤ Supporting VoIP phones in branch offices
➤ Edge switch for compact business networks
🤝 Customer Assurance
🛡️ Warranty / Guarantee: Manufacturer warranty available through TP-Link
🔄 Returns Policy: Returns accepted per reseller terms and conditions
🚚 Shipping Info: Delivered via trusted logistics partners with tracking support
📞 Customer Support: Assistance available through TP-Link official support channels and authorized resellers
👉 Call to Action
Simplify edge deployments with the TP-Link SG2005P-PD — compact PoE switching made efficient.
