TP-Link 5 PORT 10/100MBPS SWITCH WITH 4 PORT PoE TL SF1005P

$60.00 SGD

12 in stock

Less than 12 items left!
TP-Link 5 PORT 10/100MBPS SWITCH WITH 4 PORT PoE TL SF1005P
TP-Link 5 PORT 10/100MBPS SWITCH WITH 4 PORT PoE TL SF1005P
$60.00 SGD

TL-SF1005P

5-Port 10/100Mbps Desktop Switch with 4-Port PoE+

  • 5? 10/100 Mbps RJ45 ports
  • 4? PoE+ ports transfer data and power on individual cables
  • Works with IEEE 802.3af/at compliant PDs
  • Supports PoE Power up to 30 W for each PoE port
  • Supports PoE Power up to 67 W for all PoE ports*
  • Up to 250m data and power transmitting range under Extend Mode**
  • Priority Mode ensures high priority of ports 1?2?to guarantee the quality of sensitive application
  • Plug and play with no configuration required
HARDWARE FEATURES
Interface 5? 10/100 Mbps RJ45 Ports (4? 10/100 Mbps 802.3af/at PoE+ ports)
AUTO Negotiation/AUTO MDI/MDIX
Network Media 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100? STP (maximum 100m)
100BASE-TX: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100? STP (maximum 100m)
Fan Quantity Fanless
Physical Security Lock Yes
External Power Supply External Power Adapter (Output: 53.5 V DC / 1.31 A)
Packet Forwarding Rate 0.744 Mpps
PoE Ports (RJ45) Standard: 802.3 af/at compliant
PoE Ports: Ports 1?4
Power Supply: 67 W
Mac Address Table 2K
Jumbo Frame 2 KB
Switching Capacity 1 Gbps
Dimensions ( W x D x H ) 3.9 x 3.9 x 1.0 in
(100 x 98 x 25 mm)
Max Power Consumption 1.9 W (no PD connected)
74 W (with 67 W PD connected)
Max Heat Dissipation 6.5 BTU/h(no PD connected)
252.3 BTU/h(with 67 W PD connected)
SOFTWARE FEATURES
Transmission Method Store-And-Forward
Advanced Functions Compatible With IEEE 802.3af/at Compliant PDs
Extend Mode Button (Ports 1?4)
Priority Mode Button (Ports 1?2)
Mac Address Auto-Learning And Auto-Aging
IEEE802.3x Flow Control For Full-Duplex Mode And Backpressure For Half-Duplex Mode
OTHERS
Certification FCC, CE, RoHS
Package Contents TL-SF1005P, Power Adapter, Installation Guide
Environment Operating Temperature: 0?40 ? (32?104 ?)
Storage Temperature: -40?70 ? (-40?158 ?)
Operating Humidity: 10?90% RH non-condensing
Storage Humidity: 5?90% RH non-condensing
