🛍️ Product Name
StarTech MPO12PL5M – 5m MTP (Female)/PC to MTP (Female)/PC OM3 Multimode 12-Fiber Cable, Type-A, 50/125µm, Aqua Jacket, Plenum Rated (OFNP)
📦 Product Overview
The StarTech MPO12PL5M is a 5-meter OM3 multimode fiber optic cable engineered for high-bandwidth 40G applications in data centers, enterprise networks, and SAN environments. Featuring a 12-fiber MTP/MPO female-to-female interface with Type-A polarity, this cable ensures low-loss signal transmission and is plenum-rated for safe installation in air-handling spaces.
🌟 Top Highlights
🔌 12-Fiber MTP/MPO Interface – Supports 40G Ethernet and QSFP+ transceivers
🚀 OM3 Multimode 50/125µm Fiber – Optimized for short-range high-speed data transmission
🔥 Plenum-Rated OFNP Jacket – Suitable for installation in air ducts and ceiling spaces
📏 5-Meter Length – Ideal for extended rack-to-rack or patch panel runs
🧩 Type-A Polarity – Straight-through configuration for standard fiber deployments
📐 Technical Details
| Specification | Details |
|---|---|
| Cable Length | 5 meters (16.4 feet) |
| Connector A | MTP (Female) with PC polish |
| Connector B | MTP (Female) with PC polish |
| Fiber Type | OM3 Multimode 50/125µm LOMMF |
| Fiber Count | 12 fibers |
| Polarity | Type-A (Straight-through) |
| Jacket Rating | OFNP (Plenum) |
| Jacket Color | Aqua |
| Insertion Loss | ≤ 0.35 dB (typical) |
| Return Loss | ≥ 20 dB |
| Operating Temperature | -10°C to 60°C |
| Storage Temperature | -40°C to 85°C |
💡 Why You Should Buy It
✅ Built for high-speed 40G networking environments
✅ Plenum-rated for safe deployment in air-handling zones
✅ Low-loss performance ensures reliable signal transmission
✅ Compatible with QSFP+ transceivers and MTP/MPO infrastructure
🎯 Recommended Use Cases
➤ Data center backbone connectivity
➤ SAN and enterprise switch uplinks
➤ High-density patch panel installations
➤ QSFP+ to QSFP+ fiber links
🤝 Customer Assurance
🛡️ Warranty / Guarantee: Coverage available through manufacturer support
🔄 Returns Policy: Returns accepted as per standard reseller terms and conditions
🚚 Shipping Info: Delivery handled by reliable logistics partners with tracking support
📞 Customer Support: Assistance available via official support channels and authorized resellers
👉 Call to Action
Deploy high-performance fiber links with StarTech’s plenum-rated OM3 MTP/MPO cable solution
