🛍️ Product Name
StarTech MPO12PL3M – 3m MTP (Female)/PC to MTP (Female)/PC OM3 Multimode 12-Fiber Cable, Type-A, 50/125µm, Aqua Jacket, Plenum Rated (OFNP)
📦 Product Overview
The StarTech MPO12PL3M is a 3-meter OM3 multimode fiber optic cable designed for high-speed 40G networking in data centers, SANs, and enterprise environments. Featuring a 12-fiber MTP/MPO female-to-female connection with Type-A polarity, this cable supports low-loss, high-density installations with a plenum-rated OFNP jacket for maximum safety in air-handling spaces.
🌟 Top Highlights
🔌 12-Fiber MTP/MPO Interface – Ideal for 40G Ethernet and QSFP+ transceivers
🚀 OM3 Multimode 50/125µm Fiber – Supports up to 40Gbps over short distances
🔥 Plenum-Rated OFNP Jacket – Compliant for installation in air-handling spaces
📏 3-Meter Length – Flexible for rack-to-rack or patch panel connections
🧩 Type-A Polarity – Straight-through configuration for standard deployments
📐 Technical Details
| Specification | Details |
|---|---|
| Cable Length | 3 meters (10 feet) |
| Connector A | MTP (Female) with PC polish |
| Connector B | MTP (Female) with PC polish |
| Fiber Type | OM3 Multimode 50/125µm LOMMF |
| Fiber Count | 12 fibers |
| Polarity | Type-A (Straight-through) |
| Jacket Rating | OFNP (Plenum) |
| Jacket Color | Aqua |
| Insertion Loss | ≤ 0.35 dB (typical) |
| Return Loss | ≥ 20 dB |
| Operating Temperature | -10°C to 60°C |
| Storage Temperature | -40°C to 85°C |
💡 Why You Should Buy It
✅ Designed for high-speed 40G networking environments
✅ Plenum-rated for safe installation in air ducts and ceilings
✅ Low insertion loss ensures signal integrity and performance
✅ Compatible with QSFP+ and MTP/MPO-based infrastructure
🎯 Recommended Use Cases
➤ Data center high-speed interconnects
➤ Storage Area Network (SAN) deployments
➤ QSFP+ to QSFP+ switch uplinks
➤ High-density patch panel installations
🤝 Customer Assurance
🛡️ Warranty / Guarantee: Coverage available through manufacturer support
🔄 Returns Policy: Returns accepted as per standard reseller terms and conditions
🚚 Shipping Info: Delivery handled by reliable logistics partners with tracking support
📞 Customer Support: Assistance available via official support channels and authorized resellers
👉 Call to Action
Upgrade your fiber infrastructure with StarTech’s high-performance, plenum-rated MTP/MPO solution
