🛍️ Product Name
StarTech MPO8LCPL1M – 1m MTP (Female)/PC to 4x LC/PC Duplex Breakout OM3 Multimode 8-Fiber Cable, Type-A, 50/125µm, Aqua Jacket, Plenum Rated (OFNP), Push-Pull Tab
📦 Product Overview
The StarTech MPO8LCPL1M is a 1-meter OM3 multimode fiber breakout cable designed for high-speed 40G deployments in data centers and enterprise networks. It features a single MTP (Female) connector on one end and breaks out into four LC duplex connectors, enabling seamless QSFP+ to SFP+ transitions. The plenum-rated OFNP jacket ensures safe installation in air-handling spaces, and the push-pull tab simplifies handling in dense patch panels.
🌟 Top Highlights
🔌 Breakout Design – MTP to 4x LC duplex for QSFP+ to SFP+ transitions
🚀 OM3 Multimode 50/125µm Fiber – Supports 40Gbps over short distances
🔥 Plenum-Rated OFNP Jacket – Safe for air-handling installations
📏 1-Meter Length – Ideal for short rack-to-switch or panel runs
🧲 Push-Pull Tab – Simplifies insertion and removal in high-density setups
📐 Technical Details
| Specification | Details |
|---|---|
| Cable Length | 1 meter (3.3 feet) |
| Connector A | MTP (Female) with PC polish |
| Connector B | 4x LC/PC Duplex connectors |
| Fiber Type | OM3 Multimode 50/125µm LOMMF |
| Fiber Count | 8 fibers |
| Polarity | Type-A (Straight-through) |
| Jacket Rating | OFNP (Plenum) |
| Jacket Color | Aqua |
| Insertion Loss | ≤ 0.35 dB (typical) |
| Return Loss | ≥ 20 dB |
| Push-Pull Tab | Yes, for easy access |
| Operating Temperature | -10°C to 60°C |
| Storage Temperature | -40°C to 85°C |
💡 Why You Should Buy It
✅ Enables QSFP+ to SFP+ breakout connectivity
✅ Plenum-rated for safe deployment in ceiling and duct spaces
✅ Push-pull tab simplifies handling in dense racks
✅ Low-loss OM3 fiber ensures reliable 40G performance
🎯 Recommended Use Cases
➤ Data center switch-to-server breakout
➤ SAN and enterprise fiber deployments
➤ QSFP+ to 4x SFP+ transceiver connections
➤ High-density patch panel installations
🤝 Customer Assurance
🛡️ Warranty / Guarantee: Coverage available through manufacturer support
🔄 Returns Policy: Returns accepted as per standard reseller terms and conditions
🚚 Shipping Info: Delivery handled by reliable logistics partners with tracking support
📞 Customer Support: Assistance available via official support channels and authorized resellers
👉 Call to Action
Optimize short-range fiber breakout with StarTech’s plenum-rated OM3 MTP to LC solution
