GIGABYTE NVMe SSD 128GB ; Interface. PCI-Express 3.0 x4, NVMe 1.3 ; Form Factor. M.2 2280

GIGABYTE NVMe SSD 128GB

• Form Factor: M.2 2280
• Interface: PCI-Express 3.0 x4, NVMe 1.3
• Total Capacity: 128GB*
• Warranty: Limited 5-year or 110TBW
• Sequential Read Speed : up to 1550 MB/s**
• Sequential Write speed : up to 550 MB/s**
• HMB (Host Memory Buffer) supported
• TRIM & S.M.A.R.T supported

SPECIFICATIONS

• Interface
  PCI-Express 3.0 x4, NVMe 1.3
• Form Factor
  M.2 2280
• Total Capacity
  128GB
• NAND
  NAND Flash
• External DDR Cache
  N/A
• Sequential Read speed
  Up to 1550 MB/s
• Sequential Write speed
  Up to 550 MB/s
• Random Read IOPS
  Up to 100k
• Random Write IOPS
  Up to 130k
• Dimension
  80 x 22 x 2.3 mm
• Mean time between failure (MTBF)
  1.5M hours
• Max. Operating Power
  Read:2.2W
  Write:1.7W
• Power Consumption (Idle, PS3)
  30mW
• Power Consumption(PS4, L1.2)
  5mW
• Temperature (Operating)
  0°C to 70°C
• Temperature (Storage)
  -40°C to 85°C
