Edimax IAP1200 AC1200 In-Wall Dual-Band PoE Access Point (EU Type) – 802.11ac, 2×2 MIMO, 32 SSIDs, Seamless Roaming, Built-in RADIUS
📦 Product Overview
The Edimax IAP1200 is a wall-mounted dual-band wireless access point designed for high-density BYOD environments such as hotels, offices, and campus networks. Supporting simultaneous 2.4GHz and 5GHz operation with 802.11ac Wave 1 speeds up to 1200Mbps, it features 2×2 MIMO antennas, 802.3af PoE support, and a built-in RADIUS server for up to 256 user accounts. With up to 32 SSIDs (16 per band), VLAN tagging, and seamless roaming, the IAP1200 ensures secure, scalable, and centrally manageable wireless coverage in a compact in-wall form factor.
🌟 Top Highlights
📶 Dual-Band AC1200 Wi-Fi – 300Mbps @2.4GHz + 867Mbps @5GHz
🧱 In-Wall Design – Ultra-slim housing with EU wall box compatibility
🔌 802.3af PoE Powered – Single cable for data + power
🧠 Built-in RADIUS Server – Supports up to 256 user accounts
🔐 32 SSIDs + VLAN – 16 per band for secure segmentation
🚶 Seamless Roaming – Ideal for multi-AP deployments
📐 Technical Details
| Specification | Details |
|---|---|
| Model | IAP1200 |
| Wireless Standard | 802.11a/b/g/n/ac (Wi-Fi 5) |
| Max Data Rate | 1200Mbps (300 + 867) |
| Frequency Bands | 2.4GHz & 5GHz (simultaneous) |
| Antenna | 2 × internal 2dBi (2.4GHz), 2 × internal 3dBi (5GHz) |
| PoE Support | IEEE 802.3af |
| LAN Ports | 2 × 10/100/1000Mbps RJ-45 |
| SSIDs | Up to 32 (16 per band) |
| Security | WPA/WPA2-PSK, WPA/WPA2-Enterprise, 802.1X, MAC filtering |
| Management | Web UI, SNMP, AP Controller, RADIUS |
| Mounting | In-wall (EU standard box) |
| Dimensions | 86 × 86 × 45 mm |
Sources: [Edimax Official Product Page](https://www.edimax.com/edimax/merchandise/merchandise_detail/data/edimax/global/smb_access_points_ac1200/iap1200/)
💡 Why You Should Buy It
✅ Ideal for hotels, offices, and multi-tenant buildings
✅ Supports seamless roaming and multiple SSIDs
✅ PoE simplifies installation with no extra power adapters
✅ Built-in RADIUS and VLAN for secure user segmentation
🎯 Recommended Use Cases
➤ Hospitality Wi-Fi deployments
➤ Office and campus wireless networks
➤ Multi-SSID guest/staff segmentation
➤ PoE-powered wall-mount installations
