🛍️ Product Name
D-Link DGS-3630-28PC L3 Managed Switch (20 × PoE Gigabit, 4 × PoE/SFP Combo, 4 × 10G SFP+, 370W / 760W Power Budget)
📦 Product Overview
The D-Link DGS-3630-28PC is a high-performance Layer 3 managed switch designed for enterprise, campus, and surveillance networks. Featuring 20 PoE Gigabit ports, 4 PoE/SFP combo ports, and 4 × 10G SFP+ uplinks, it delivers powerful connectivity and advanced management. With a scalable PoE budget of 370W, expandable to 760W with an external RPS, it is ideal for powering IP cameras, access points, and VoIP phones while ensuring reliable backbone performance.
🌟 Top Highlights
⚡ PoE+ Power – 370W budget, expandable to 760W with RPS
📶 10G Uplinks – 4 × SFP+ ports for backbone scalability
🔒 Layer 3 Features – Static/dynamic routing, VLANs, ACLs, and advanced security
🛠️ Modular OS – Flexible software image upgrades for feature expansion
🏗️ Enterprise Reliability – Redundant power support and robust design
📐 Technical Details
| Specification | Details |
|---|---|
| Switch Type | Layer 3 Managed Gigabit PoE Switch |
| Access Ports | 20 × Gigabit PoE |
| Combo Ports | 4 × Gigabit PoE/SFP |
| Uplink Ports | 4 × 10G SFP+ |
| PoE Standard | IEEE 802.3af/at (PoE+) |
| PoE Budget | 370W (expandable to 760W with RPS) |
| Switching Capacity | 336 Gbps |
| Packet Forwarding Rate | 250 Mpps |
| MAC Address Table | 32K entries |
| Stacking Capacity | Up to 9 units per stack |
| Management Features | Web UI, CLI, SNMP, VLAN, QoS, ACL, IGMP Snooping, Loopback Detection, Port Mirroring |
| Layer 3 Features | Static & Dynamic Routing, IPv4/IPv6 support |
| Dimensions | Approx. 440 × 250 × 44 mm (1U rackmount) |
| Weight | Approx. 4.8 kg |
💡 Why You Should Buy It
✅ High PoE budget supports multiple powered devices
✅ 10G uplinks ensure backbone scalability
✅ Layer 3 features enable advanced enterprise networking
✅ Modular OS allows flexible feature upgrades
🎯 Recommended Use Cases
➤ Enterprise and campus networks
➤ IP surveillance deployments
➤ VoIP phone systems
➤ High-density Wi-Fi access point installations
🤝 Customer Assurance
🛡️ Warranty / Guarantee: Coverage available through manufacturer support
🔄 Returns Policy: Returns accepted as per standard reseller terms and conditions
🚚 Shipping Info: Delivery handled by reliable logistics partners with tracking support
📞 Customer Support: Assistance available via official support channels and authorized resellers
👉 Call to Action
Empower your enterprise with scalable Layer 3 PoE switching — choose the D-Link DGS-3630-28PC today.
