🛍️ Product Name
ATEN CE700A USB VGA KVM Extender – Dual Console, 150m over Cat 5e, Audio Support, ESD Protection
📦 Product Overview
The ATEN CE700A is a compact USB VGA KVM extender that allows access to a computer from up to 150 meters away using a single Cat 5e cable. It supports dual-console operation, letting users control the system from both local and remote stations. With support for high-resolution video, audio transmission, and built-in ESD protection, it’s ideal for industrial control, kiosks, and secure remote access environments.
🌟 Top Highlights
🖥️ 150m Transmission – Extend VGA, USB, and audio over Cat 5e cable
🧩 Dual Console Support – Operate from both local and remote stations
🎧 Audio Enabled – 3.5mm stereo jack for audio pass-through
⚡ ESD Protection – 8KV contact / 15KV air safeguard
🔌 Plug-and-Play – No software installation required
📐 Technical Details
| Specification | Details |
|---|---|
| Model | CE700A |
| Function | USB VGA KVM Extender |
| Max Distance | 150 meters over Cat 5e |
| Video Resolution | 1920×1200 @ 30m, 1600×1200 @ 100m, 1280×1024 @ 150m |
| Video Interface | VGA (HDDB15) |
| USB Interface | USB Type B (local), USB Type A (remote) |
| Audio Support | 3.5mm stereo jack |
| ESD Protection | 8KV contact / 15KV air |
| Power Supply | DC 5.3V, 2.4A (external adapter) |
| Dimensions | 13.00 × 8.70 × 2.50 cm (each unit) |
| Weight | ~0.3 kg per unit |
| Mounting | Desktop or wall-mount |
| Operating Temp | 0°C to 50°C |
| Certifications | CE, FCC |
💡 Why You Should Buy It
✅ Extend control up to 150m with a single cable
✅ Dual-console access for flexible operation
✅ High-resolution VGA video and audio support
✅ Compact and reliable for industrial or commercial use
🎯 Recommended Use Cases
➤ Remote workstation access in control rooms
➤ Secure server management from a distance
➤ Kiosk and digital signage control
➤ Classroom or training room AV setups
🤝 Customer Assurance
🛡️ Warranty / Guarantee: 3-year ATEN limited warranty
🔄 Returns Policy: Returns accepted as per standard reseller terms and conditions
🚚 Shipping Info: Delivery handled by reliable logistics partners with tracking support
📞 Customer Support: Assistance available via ATEN and authorized resellers
👉 Call to Action
Extend your control with ATEN CE700A — dual-console USB VGA access up to 150 meters
