🛍️ Product Name
OEM AT-FS750/16 WebSmart Switch – 16 x 10/100TX Fast Ethernet Ports + 2 x Gigabit Copper/SFP Combo Ports, Rackmountable, Web-Based Management
📦 Product Overview
The OEM AT-FS750/16 is a compact WebSmart Fast Ethernet switch featuring 16 10/100TX ports and 2 combo Gigabit Copper/SFP uplinks. Designed for small to mid-sized networks, it offers essential Layer 2 management capabilities including VLANs, QoS, and port mirroring via an intuitive web interface. Ideal for edge deployments, it combines plug-and-play simplicity with basic control features.
🌟 Top Highlights
🔌 16 x 10/100TX Ports – Reliable Fast Ethernet access
🚀 2 x Gigabit Combo Ports – Flexible uplink via Copper or SFP
🧠 WebSmart Management – VLANs, QoS, port mirroring
📦 Rackmountable Design – Standard 1U form factor
🔒 Port Security – Basic access control features
📐 Technical Details
| Specification | Details |
|---|---|
| Model | AT-FS750/16 |
| Ethernet Ports | 16 x 10/100TX |
| Gigabit Uplink Ports | 2 x 1000T/SFP Combo |
| Switching Capacity | 7.2 Gbps |
| Forwarding Rate | 5.36 Mpps |
| MAC Address Table | 8K entries |
| VLAN Support | IEEE 802.1Q, up to 64 VLANs |
| QoS | IEEE 802.1p, 4 queues per port |
| Jumbo Frame | Up to 9K bytes |
| Management | WebSmart GUI |
| Power Supply | Internal AC |
| Dimensions | 44 x 20.9 x 4.4 cm |
| Weight | 2.5 kg |
| Operating Temperature | 0°C to 50°C |
| Certifications | FCC Class A, CE |
💡 Why You Should Buy It
✅ Combines unmanaged simplicity with basic management
✅ Flexible uplink options with Gigabit combo ports
✅ Ideal for small office or branch deployments
✅ Rackmountable and energy-efficient design
🎯 Recommended Use Cases
➤ Edge switch for small business networks
➤ Departmental VLAN segmentation
➤ Uplink aggregation via Gigabit combo ports
➤ Cost-effective managed switch alternative
🤝 Customer Assurance
🛡️ Warranty / Guarantee: Coverage available through manufacturer support
🔄 Returns Policy: Returns accepted as per standard reseller terms and conditions
🚚 Shipping Info: Delivery handled by reliable logistics partners with tracking support
📞 Customer Support: Assistance available via official support channels and authorized resellers
👉 Call to Action
Deploy the AT-FS750/16 WebSmart Switch for flexible, reliable edge connectivity
