AX6100 Tri-Band WiFi 6
- Next-Gen Wi-Fi6 Technology — With OFDMA and MU-MIMO, RT-AX92U enables more efficient, stable, and faster transmission even when multiple devices are transmitting data at the same time.
- Flexible Wi-Fi for connected devices — RT-AX92U comes with 802.11n, ac and ax bands, which provides channels for all kinds of devices, including legacy or cutting-edge devices.
- Powerful Whole-home Wi-Fi System, the Way You Want — RT-AX92U supports ASUS AiMesh-a powerful, flexible whole-home mesh system technology. AiMesh gives you time-saving central control, and seamless roaming capability, users can use a mix of ASUS router models.
- Commercial-grade network security for family — AiProtection Pro protects all the connected devices on your home network and advanced parental controls allow you to manage the family
SPECIFICATIONS
Model Name
RT-AX92U(2-PK)
Network Standard
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
WiFi 4 (802.11n)
WiFi 5 (802.11ac)
WiFi 6 (802.11ax)
IPv4
IPv6
IEEE 802.11b
IEEE 802.11g
WiFi 4 (802.11n)
WiFi 5 (802.11ac)
WiFi 6 (802.11ax)
IPv4
IPv6
Product Segment
AX6100 ultimate AX performance : 400 Mbps+ 867 Mbps+ 4804 Mbps
AX technology
Yes
Data Rate
WiFi 4 (802.11n) : up to 150 Mbps
WiFi 4 (802.11n) TurboQAM : up to 150 Mbps
WiFi 5 (802.11ac) : up to 433 Mbps
WiFi 4 (802.11n) TurboQAM : up to 150 Mbps
WiFi 5 (802.11ac) : up to 433 Mbps
Antenna
External antenna x 4, Internal antenna X 2
Transmit/Receive
2.4GHz 2×2
5GHz 2×2
5GHz-2 4×4
5GHz 2×2
5GHz-2 4×4
Processor
1.8 GHz dual-core processor
Memory
256 MB Flash, 512 MB RAM
Boosts speed
OFDMA (Orthogonal Frequency Division Multiple Access)
Beamforming: standard-based and universal
20/40/80/160 MHz bandwidth
Beamforming: standard-based and universal
20/40/80/160 MHz bandwidth
Operating Frequency
2.4G Hz, 5 GHz-1, 5 GHz-2
Ports
RJ45 for Gigabits BaseT for WAN x 1, RJ45 for Gigabits BaseT for LAN x 4
USB 2.0 x 1
USB 3.0 x 1
USB 2.0 x 1
USB 3.0 x 1
Button
WPS Button, Reset Button, Power Button
LED Indicator
Power x 1
Wi-Fi x 3
WAN x 1
LAN x 1
Wi-Fi x 3
WAN x 1
LAN x 1
Power Supply
AC Input : 110V~240V(50~60Hz)
DC Output : 19 V with max. 1.75 A current
DC Output : 19 V with max. 1.75 A current
Package content
‧RJ-45 Cable x1
‧Power Adapter x2
‧QSG x1
‧Power Adapter x2
‧QSG x1
Product Weight (g)
651
AiMesh
AiMesh
Primary AiMesh router
AiMesh node
Primary AiMesh router
AiMesh node
Router APP
ASUS Router APP
Game
Game Boost / Acceleration
WTFast
WTFast
Alexa
Support Alexa skill
IFTTT
Support IFTTT
AiProtection
AiProtection Pro
Router Security Assessment
Malicious site blocking
Two-Way IPS
Infected Device Prevention and Blocking
Router Security Assessment
Malicious site blocking
Two-Way IPS
Infected Device Prevention and Blocking
Parental Control
Parental Control
Parental Control Customized Internet schedule
Maximum Parental Control profile : 16
Maximum Parental Control content filter rule : 16
Parental Control Customized Internet schedule
Maximum Parental Control profile : 16
Maximum Parental Control content filter rule : 16
Traffic Control
Adaptive QoS
Bandwidth Monitor
Bandwidth limiter
Maximum Bandwidth limiter rule : 32
Traffic Monitor
Real-time traffic monitor
Wired Traffic Monitor
Wireless Traffic Monitor
Traffic Analyzer
Traffic analysis period : Daily, Weekly, Monthly
Website history
Bandwidth Monitor
Bandwidth limiter
Maximum Bandwidth limiter rule : 32
Traffic Monitor
Real-time traffic monitor
Wired Traffic Monitor
Wireless Traffic Monitor
Traffic Analyzer
Traffic analysis period : Daily, Weekly, Monthly
Website history
Wireless
IPv6
Wi-Fi Encryption : WPA3-Personal, WPA2-Personal, WPA-Personal, WPA-Enterprise , WPA2-Enterprise , WPS support
UTF-8 SSID
Guest Network
Maximum Guest Network rule : 2.4GHz x3, 5GHz-1 x3,5GHz-2 x3
Guest Network Connection time limit
Guest Network Encryption : Open system, WPA/WPA2-Personal
WPS
WiFi MAC address filter
Maximum MAC filters : 64
Wireless scheduler
Airtime fairness
RADIUS Client
Universal beamforming
Explicit beamforming
Wi-Fi Encryption : WPA3-Personal, WPA2-Personal, WPA-Personal, WPA-Enterprise , WPA2-Enterprise , WPS support
UTF-8 SSID
Guest Network
Maximum Guest Network rule : 2.4GHz x3, 5GHz-1 x3,5GHz-2 x3
Guest Network Connection time limit
Guest Network Encryption : Open system, WPA/WPA2-Personal
WPS
WiFi MAC address filter
Maximum MAC filters : 64
Wireless scheduler
Airtime fairness
RADIUS Client
Universal beamforming
Explicit beamforming
WAN
Internet connection Type : PPPoE, PPTP, L2TP, Automatic IP, Static IP
Dual WAN
WAN Aggregation
3G/4G LTE dongle
Android tethering
Port forwarding
Maximum port forwarding rule : 64
Port triggering
Maximum port triggering rule : 32
DMZ
DDNS
NAT Passthrough : Automatic IP, Static IP, PPPoE(MPPE supported), PPTP, L2TP
Let’s Encrypt
Dual WAN
WAN Aggregation
3G/4G LTE dongle
Android tethering
Port forwarding
Maximum port forwarding rule : 64
Port triggering
Maximum port triggering rule : 32
DMZ
DDNS
NAT Passthrough : Automatic IP, Static IP, PPPoE(MPPE supported), PPTP, L2TP
Let’s Encrypt
LAN
DHCP Server
IGMP snooping
IPTV
LAN Link Aggregation
Manually assign IP address
Maximum manually assign IP address rule : 64
IGMP snooping
IPTV
LAN Link Aggregation
Manually assign IP address
Maximum manually assign IP address rule : 64
VPN
VPN Client L2TP
VPN Client OVPN
VPN Client PPTP
VPN Server IPSec
VPN Server OVPN
VPN Server PPTP
VPN Client OVPN
VPN Client PPTP
VPN Server IPSec
VPN Server OVPN
VPN Server PPTP
