AC750 Dual Band WiFi Router
- High-speed performance
Concurrent speed up to a combined 750 Mbps data rate. - Smart control with ASUSWRT
With the ASUSWRT dashboard UI, setup, monitor, and control network applications all in one intuitive area. - Robust external antenna
3 external strong antenna enhances signal transmission - High Power Design
In pursuit of ultimate capability - Gigabit Ethernet
Data transfer 10 times faster than 10/100 Fast Ethernet devices
SPECIFICATIONS
| Network Standard | IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IPv4, IPv6 |
| Product Segment | AC750 complete AC performance : 300+433 Mbps |
| Coverage | Medium homes |
| Data Rate | 802.11n : up to 300 Mbps 802.11ac : up to 433 Mbps |
| Antenna | External antenna x 3 |
| Transmit/Receive | MIMO technology 2.4 GHz 2 x 2 5 GHz 1 x 1 |
| Memory | 8 MB Flash 64 MB RAM |
| Operating Frequency | 2.4 GHz / 5 GHz |
| Encryption | 64-bit WEP, 128-bit WEP, WPA2-PSK, WPA-PSK, WPA-Enterprise , WPA2-Enterprise , Radius with 802.1x, WPS support |
| Firewall & Access Control | Firewall：SPI intrusion detection Access control：Guest access, Parental control, Network service filter, URL/Port filter |
| WAN Connection Type | Internet connection type : Automatic IP, Static IP, PPPoE(MPPE supported), PPTP, L2TP |
| Ports | RJ45 for 10/100/1000 BaseT for WAN x 1, RJ45 for 10/100/1000 BaseT for LAN x 2 |
| Button | WPS Button, Reset Button, Power Button |
| Features | SmartQoS – WMM – User definable rules for IP/MAC/Port – Upload and download bandwidth management – ACK/SYN/FIN/RST/ICMP with highest priority Parental Control Guest Network : 2.4 GHz x 3, 5 GHz x 3 VPN server : IPSec Pass-Through, PPTP Pass-Through, L2TP Pass-Through, PPTP Server VPN client : PPTP client, L2TP client |
| LED Indicator | LAN x 2 Wi-Fi x 2 WAN x 1 Power x 1 |
| Power Supply | AC Input : 110V~240V(50~60Hz) DC Output : 12 V with max. 1 A current |
| OS Support | Windows® 10 Windows® 8.1 Windows® 8 , 32bit/64bit Windows® 7 , 32bit/64bit Windows® Vista , 32bit/64bit Windows® 2000 Windows® XP , 32bit/64bit Windows® Server 2003 Windows® Server 2008 Mac OS X 10.1 Mac OS X 10.4 Mac OS X 10.5 Mac OS X 10.6 Mac OS X 10.7 Mac OS X 10.8 Mac OS X Linux Kernel (Support Ubuntu only) Linux Android |
| Dimensions | 320 x 190 x 35 ~ mm (WxDxH) (Without Bezel) |
| Weight | 285 g |
| Package Content | ．RT-AC53 Wireless-AC750 Router ．RJ-45 Cable ．Power Adapter ．Quick Start Guide ．Warranty Card |
| Operation mode | Wireless router mode Range extender mode Access point mode |
