🛍️ Product Name
ASRock DeskMini X300 Barebones – Model 90BXG3T01-A30IA0W, AMD AM4 Socket, Supports Ryzen 5000G/4000G/3000G CPUs, DDR4 SO-DIMM, Dual M.2 NVMe, 2× SATA, USB-C, 1.92L Form Factor
📦 Product Overview
The ASRock DeskMini X300 is a barebones mini PC platform built for AMD AM4 socket APUs. It supports Ryzen 5000G, 4000G, and 3000G series processors up to 65W TDP, with overclocking enabled via the X300 chipset. The system includes dual M.2 NVMe slots, two 2.5″ SATA bays, and dual-channel DDR4 SO-DIMM memory support up to 64GB. With HDMI, DisplayPort, D-Sub, USB-C, and Gigabit LAN, it offers versatile connectivity in a 1.92-liter chassis.
🌟 Top Highlights
🧠 AM4 Socket – Supports Ryzen 5000G/4000G/3000G APUs
⚡ X300 Chipset – Enables overclocking and performance tuning
💾 Dual M.2 NVMe Slots – PCIe Gen3 x4 and x2/x4 support
🧮 DDR4 SO-DIMM – Up to 64GB, dual-channel
📦 Compact 1.92L Chassis – Space-saving and efficient
📐 Technical Details
| Specification | Details |
|---|---|
| Model Number | 90BXG3T01-A30IA0W |
| CPU Support | AMD AM4 (Ryzen 5000G, 4000G, 3000G, Raven Ridge) |
| Chipset | AMD X300 |
| Memory Support | 2× DDR4 SO-DIMM, up to 64GB, 3200/2933MHz |
| Storage | 2× M.2 NVMe (PCIe Gen3 x4, x2/x4), 2× 2.5″ SATA 6Gb/s |
| Graphics Output | HDMI, DisplayPort, D-Sub |
| Audio | Realtek ALC233 HD Audio |
| LAN | Realtek RTL8111H Gigabit Ethernet |
| USB Ports | USB 3.2 Gen1 Type-C, USB 3.2 Gen1 Type-A, USB 2.0 |
| Expansion | M.2 slot for Wi-Fi module |
| Power Supply | 120W external adapter |
| Dimensions | 155 × 155 × 80 mm |
| Form Factor | Mini-STX (1.92L) |
💡 Why You Should Buy It
✅ Supports latest Ryzen APUs with integrated graphics
✅ Dual NVMe slots for fast storage
✅ Compact and upgradeable barebones platform
✅ Ideal for HTPC, office, and embedded builds
🎯 Recommended Use Cases
➤ Home theater PC (HTPC)
➤ Office and productivity workstation
➤ Embedded or kiosk deployments
➤ Compact gaming or media center builds
🤝 Customer Assurance
🛡️ Warranty / Guarantee: Coverage available via ASRock-authorized support
🔄 Returns Policy: Returns accepted as per standard reseller terms and conditions
🚚 Shipping Info: Delivery handled by reliable logistics partners with tracking support
📞 Customer Support: Assistance available via ASRock support channels and authorized resellers
👉 Call to Action
Build your compact Ryzen-powered system with the ASRock DeskMini X300 – small in size, big in capability.
