ποΈ Product Name
ARUBA JL685A Instant On 1930 48G 4SFP/SFP+ Switch β 48-Port Gigabit Smart Managed Switch with 4 SFP/SFP+ Uplink Slots
π¦ Product Overview
The Aruba Instant On JL685A 1930 48G 4SFP/SFP+ Switch is a high-density smart-managed switch designed for small and medium businesses that require robust wired connectivity and high-speed uplinks. With 48 Gigabit Ethernet ports and 4 SFP/SFP+ uplinks supporting up to 10Gbps, it enables seamless access layer deployments and efficient backbone connections. Its intuitive management via web GUI and mobile app simplifies setup, while advanced Layer 2+ features ensure secure and optimized traffic control across VLANs and devices.
π Top Highlights
π 48x Gigabit Ports β High-density access for desktops, printers, and access points
π 4x SFP/SFP+ Uplinks β Supports 1G and 10G fiber modules for fast backbone links
π± Instant On App Support β Simplified setup and remote management
π‘οΈ Layer 2+ Features β VLANs, QoS, IGMP snooping, and link aggregation
π Security Controls β Access control lists and port security for safer deployments
π Technical Details
| Specification | Details |
|---|---|
| Model Number | JL685A |
| Switch Type | Smart-managed Layer 2+ Gigabit |
| Ports | 48x RJ-45 10/100/1000 Mbps |
| Uplink Slots | 4x SFP/SFP+ (1G/10G) |
| Switching Capacity | 176 Gbps |
| Forwarding Rate | 130.9 Mpps |
| MAC Address Table | 16K entries |
| VLAN Support | Up to 256 VLANs |
| Management | Web GUI, Instant On mobile app, CLI |
| Mounting | Rack-mountable |
| Power Supply | Internal, 100β240V AC |
| Dimensions | 442 x 200 x 43.9 mm |
| Weight | 3.0 kg |
π‘ Why You Should Buy It
β
Supports 10G uplinks for high-speed backbone
β
Ideal for high-density SMB deployments
β
Easy setup via mobile app or web interface
β
Trusted Aruba brand with enterprise-grade features
π― Recommended Use Cases
β€ Office LAN deployments with large device counts
β€ Server and storage connectivity
β€ Retail and hospitality environments
β€ Branch office backbone switching
π€ Customer Assurance
π‘οΈ Warranty / Guarantee: Coverage available through Aruba Instant On support
π Returns Policy: Returns accepted as per standard reseller terms and conditions
π Shipping Info: Delivery handled by reliable logistics partners with tracking support
π Customer Support: Assistance available via Aruba support portal and authorized resellers
π Call to Action
Expand your network with Arubaβs high-density smart switch built for modern business demands
